USRobotics 5686G Data/Fax Modem

  • Part: 1005521
  • Model: USR5686G
$119.87

Availability

In Stock
  • General Information
    • Manufacturer
    • U.S. Robotics
    • Manufacturer Website Address
    • http://www.usr.com
    • Brand Name
    • USRobotics
    • Product Type
    • Data/Fax Modem

The USRobotics 56K Serial Controller Faxmodem combines the superior performance and reliability of a controller-based modem with the convenience of V.92 and V.22 technologies - with up to 75% less energy use. V.22 Fast Connect, which reduces the connection sequence time for very small data transfers, and secure connectivity make this modem ideal for Point of Sale (POS) systems. The modem also enables secure Machine to Machine (M2M) applications or Remote Server Management applications for Out-of-Band remote diagnostics, troubleshooting, maintenance and back-ups of servers.

  • Warranty
    • Limited Warranty
    • 2 Year

  • Technical Information
    • Modulation
    • ITU-T V.92
    • ITU-T V.90
    • ITU-T V.34
  • Interfaces/Ports
    • Host Interface
    • Serial
    • Number of Phone Line (RJ-11) Ports
    • 2
  • Media & Performance
    • Modem Transmission Data Rate
    • 56 kbit/s
  • Power Description
    • Input Voltage
    • 9 V DC
  • Physical Characteristics
    • Form Factor
    • Desktop
    • Height
    • 1.3"
    • Width
    • 3.8"
    • Depth
    • 6.5"
    • Weight (Approximate)
    • 8.64 oz
  • Miscellaneous
    • Package Contents
      • 5686G Data/Fax Modem
      • AC Power Supply Unit
      • RJ-11 Telephone Cable (7 ft)
      • Quick Install Guide
      • CD-ROM
    • Additional Information
      • External DIP switches allows manual configuration of specific critical settings
      • Extra LEDs for better monitoring of serial signals
      • Precise manual volume control
      • Permanently store preferred modem default settings
    • System Requirements
      • Available Serial Port
      • Analog Phone Line
      • RS-232 Serial Cable
      Operating Systems:
      • Modem is compatible with Server 2012, Server 2011, Windows 8 64 bit, Win 8, Windows 7 64 bit, Win 7, Server 2008 64 bit, Server 2008, Vista 64 bit, Vista, Server 2003 64 bit, Server 2003, XP 64 bit, XP, NT 4.0, 2000, ME, 98, 95, 3.1, Linux and DOS.
      • Unimodem TSP/TAPI compliant
      • Fax software requires Microsoft Windows 95 or later
      • Modem on Hold requires Windows 2000 or later
    • Environmentally Friendly
    • Yes
    • Country of Origin
    • China
