- General Information
- Manufacturer
- Tyan Computer Corp
- Manufacturer Website Address
- http://www.tyan.com
- Brand Name
- Tyan
- Product Line
- Transport SX
- Packaged Quantity
- 1
- Product Type
- Barebone System
- Warranty
- Limited Warranty
- 3 Year
- Processor
- Number of Processors Supported
- 1
- Number of Processors Installed
- 1
- Processor Socket
- Socket SP5 LGA-6096
- Processor Supported
- EPYC
- 64-bit Processing
- Yes
- Chipset
- Chipset Manufacturer
- AMD
- Memory
- Maximum Memory Supported
- 3 TB
- Memory Technology
- DDR5 SDRAM
- Memory Standard
- DDR5-4800/PC5-38400
- Total Number of Memory Slots
- 24.0
- Storage
- Supported Storage Drive Interfaces
- PCI Express 4.0 x4
- Serial ATA
- SAS
- Supported Storage Drive Types
- SSD
- HDD
- Controllers
- Controller Type
- NVMe
- Serial ATA/600
- Display & Graphics
- Graphics Controller Manufacturer
- ASPEED
- Graphics Controller Model
- AST2600
- Graphics Memory Technology
- DDR5 SDRAM
- Graphics Memory Accessibility
- Shared
- I/O Expansions
- Number of Total Expansion Bays
- 14
- Number of 3.5" Bays
- 12
- Total Number of Expansion Slots
- 4
- Number of PCI Express x8 Slots
- 1
- Number of PCI Express x16 Slots
- 3
- Number of M.2 Interfaces
- 2
- Interfaces/Ports
- Total Number of USB Ports
- 8
- Number of USB 3.2 Gen 1 Ports
- 8
- Number of SATA Interfaces
- 12
- Number of VGA Ports
- 1
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Installed
- 2
- Maximum Power Supply Wattage
- 1200 W
- Thermal Design Power
- 400 W
- Frequency
- 50 Hz
- 60 Hz
- Physical Characteristics
- Form Factor
- Rack-mountable
- Rack Height
- 2U
- Height
- 3.4"
- Width
- 17.3"
- Depth
- 27.6"
- Miscellaneous
- Package Contents
- Transport SX TS70-B8056
- 1 x Quick Installation Guide
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS) 6
