- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com/us
- Brand Name
- TP-Link
- Product Type
- SFP (mini-GBIC)
The TL-SM311 series Fiber Module Cards are introduced for extending transfer distance. Attached to our managed/smart switches, they can extend the distance to several kilometers even tens of kilometers which can basically satisfy the distance requirement of LAN. Users can choose whether and which items to use the fiber modules according to the demand in order to lower cost.
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Application/Usage
- Data Networking
- Optical Network
- Interfaces/Ports
- Total Number of Ports
- 1
- Connector Type
- LC/UPC
- Interfaces/Ports Details
- 1 x LC/UPC Duplex 1000Base-LX Network
- Media & Performance
- Media Type Supported
- Optical Fiber
- Fiber Optic Cable Standard
- 9/125 µm
- Fiber Mode Supported
- Single-mode
- Ethernet Technology
- 1.25 Gigabit Ethernet
- Network Technology
- 1000Base-LX
- Physical Characteristics
- Form Factor
- Hot-swappable
- Miscellaneous
- Package Contents
- MiniGBIC Module
- Installation Guide
- Additional Information
- Wavelength : 1310 nm
- Distance Supported : 10 km
Features:
- CSMA/CD
- TCP/IP
- Plug-and-Play
- supports Pull-or-Plug with power on switches
- Compatibility
-
- TP-Link MC220L Gigabit Ethernet Media Converter
TP-Link Switches:
- T3700G-28TQ
- TL-SG5412F
- TL-SG5428
- TL-SL5428E
- TL-SG3210
- TL-SG3216
- TL-SG3424
- TL-SG3424P
- TL-SL3428
- TL-SL3452
- TL-SG2210P
- TL-SG2216
- TL-SG2424
- TL-SG2424P
- TL-SG2452
- TL-SL2210
- TL-SL2218
- TL-SL2428
- TL-SL2452
- Country of Origin
- China
- Environmentally Friendly
- Yes
