Perle MCR1900-DAC - 19 Slot Chassis for Media Converter and Ethernet Extender Modules

  • Part: 1005479
  • Model: 05059954
$1,536.00

Availability

In Stock
  • General Information
    • Manufacturer
    • Perle Systems, Inc
    • Manufacturer Website Address
    • http://www.perle.com
    • Brand Name
    • Perle
    • Product Type
    • Media Converter Chassis

The Perle MCR1900 Media Converter Chassis is the most reliable high density modular chassis system available today. It is ideal for enterprise and campus environments where multiple points of copper and/or fiber integration are essential. An end-to-end copper to copper, copper to fiber, multimode to single mode or multimode to multimode solution can be achieved by pairing modules in this high density chassis with another Perle MCR1900 chassis standalone media converters, or standalone Ethernet extenders. Management of Media Converter Modules and chassis can be performed with the addition of a chassis management module. For a low to mid density solution, please check out the MCR200 Media Converter Chassis.

  • Warranty
    • Limited Warranty
    • Lifetime

  • Physical Characteristics
    • Height
    • 3.5"
    • Width
    • 17.1"
    • Depth
    • 14"
    • Weight (Approximate)
    • 15.43 lb
  • Miscellaneous
    • Package Contents
      • MCR1900-DAC - 19 Slot Chassis for Media Converter and Ethernet Extender Modules
      • 15 x Empty Slot Cover Plates
      • 2U - 19" Rack Mounting Hardware
    • Additional Information
    • All modules, management module and power supplies are hot-swappable
    • Certifications & Standards
    • Emissions:
      • FCC Part 15 Class A, EN55022 Class A
      • CFR47:2003, Chapter 1, Part 15 Subpart B,(USA) Class A
      • ICES-003, Issue 4, February 2004 (Canada)
      • EN55022:1998 + A1:2000 + A2:2003 Class A
      • EN61000-3-2 : 1995, Limits for Harmonic Current Emissions
      • EN61000-3-3 : 1995, Limits of Voltage Fluctuations and Flicker
      Immunity:
      • EN55024:1998 + A1:2001 + A2:2003
      • EN61000-4-2: Electrostatic Discharge
      • EN61000-4-3: RF Electromagnetic Field Modulated
      • EN61000-4-4: Fast Transients
      • EN61000-4-5: Surge
      • EN61000-4-6: RF Continuous Conducted
      • EN61000-4-8: Power-Frequency Magnetic Field
      • EN61000-4-11: Voltage Dips and Voltage Interruptions
      Safety:
      • IEC 60950-1, First Edition (2001-10) and EN60950-1:2001, CB scheme
      • CAN/CSA-C22.2 No. 60950-1-03 and ANSI/UL 60950-1, First Edition April 1st 2003 (Recognized Component)
      Other:
      • ECCN: 5A991A
      • HTSUS Number: 8517.62.0050
    • Country of Origin
    • Taiwan
    • Environmentally Friendly
    • Yes
    • Environmental Compliance
    • Restriction of Hazardous Substances (RoHS)
    • Waste Electrical and Electronic Equipment Directive (WEEE)
    • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
