Quick Facts
- UL® approved.
- Three-way isolation, 2000-V input/output.
- Operates in harsh environments, withstanding temperatures of -40° to +185° F (-40° to +85° C).
- Features 600 W of surge suppression.
- Optical isolation protects your devices from transient surges and ground loops on your data line.
Further Details
- Adds 4000 feet (1219.2 m) and another 32 nodes to an RS-485 data circuit. By configuring one side as RS-422 and the other side as RS-485, it acts as a converter to enable a 4-wire RS-422 device to communicate with a 2-wire RS-485 device.
- Features 10-48-VDC operation and withstands temperature extremes.
- Modbus ASCII or RTU compatible.
- Automatic Send Data Control eliminates the need for driver software.
- Conveniently mount on optional DIN Rails.
- General Information
- Manufacturer
- Black Box Corporation
- Manufacturer Website Address
- http://www.blackbox.com
- Brand Name
- Black Box
- Product Type
- Signal Repeater
- Warranty
- Limited Warranty
- 5 Year
- Power Description
- Input Voltage
- 48 V DC
- Physical Characteristics
- Height
- 3.9"
- Width
- 2.9"
- Depth
- 0.9"
- Miscellaneous
- Additional Information
- Distance (Maximum) - 4000 ft. (1219.2 m)
- Operating Environment - -40° to +185° F (-40° to +85° C);Humidity: Up to 95% noncondensing
- Operation - RS-422: Full-duplex; RS-485: 2-wire half-duplex or 4-wire full-duplex
- Speed - 2400 bps to 115.2 kbps, switch-selectable; other rates available up to 460.8 kbps
- Certifications & Standards
- UL
- CE
- Country of Origin
- United States
